Envisivent Removable Flush Mount Air Return, 30” x 8” (Duct Opening)/Requires 30" x 10" Drywall Opening
Envisivent Removable Flush Mount Air Return, 30” x 8” (Duct Opening)/Requires 30" x 10" Drywall Opening
Description
Envisivent's removable air return sits completely flush against your wall creating a blended smooth aesthetic. The vent cover is completely removable and is meant to replace a vent cover for a 30" x 8" duct opening (if applicable) or wall cavity and fits into a drywall opening of 29.5" x 10".
Envisivent vent covers fit the depth of standard drywall and are easy to install, simply tape, mud, sand, and then paint directly over the already primed vent cover for that blended look you want for every room of your house.
Envisivent Removable Air Return Vents can also accommodate air filters with the use of our 1" or 2" Air Filter Clips. IMPORTANT: the size of your air filter should align with the size of the Slotted Area of the vent (refer to the "Sizing" section on the product page). If the air filter is too large it will not properly fit in behind the vent cover. Simply attach the Air Filter Clips to the inner lip of the Air Return vent frame and slide your air filter into place behind the vent cover. Shop our Air Filter Clips
THIS ITEM IS NOT SUITABLE FOR CEILING INSTALLATION WITHOUT THE USE OF OUR CEILING CLIPS WHICH CAN BE ORDERED HERE
*To ensure you select the correct Envisivent product size, be sure to review our Sizing Guide in our Resource section.
Key Features
- Four rows of 12 straight horizontal slots, totaling 48 slots
- Over 90 square inches (580 square cm) of open vent area
- 4 magnetic tabs on the vent cover for easy removal
- Metal frame screws onto the face of your drywall
- Moisture, mold, and water resistant
- Primed and ready to paint
- Eco-friendly manufacturing and non-hazardous
- Frame Material: Satin Coat Galvanized Steel
- Vent Cover Material: Triple Fibre Reinforced Cement Board
- Designed to be installed with 1/2" or 5/8" thick drywall
Sizing
| Duct Opening/or Wall Cavity |
30" x 8" |
| Drywall Opening | 29.5" x 10" |
| Vent Cover |
29.37” x 9.625” |
| Slotted Area |
28” x 8” |
| Number of Slots | 48 slots total |
| Overall Dimensions with Frame |
32” x 12.25" x 0.l5" |
| Sizing Guide | Click here for Sizing Guide |
Specs, Install & Air Flow Data
Accessories
